2026 Ram 1500 Towing & Payload by Engine
Engine choice is the primary factor determining your Ram 1500's towing and payload capability. Here's how all four engines compare:
| Engine |
Max Towing |
Max Payload |
Horsepower |
Torque |
| 3.6L Pentastar V6 with eTorque |
3,329 kg (7,340 lbs) |
812 kg (1,790 lbs) |
305 hp |
271 lb-ft |
| 5.7L HEMI V8 with eTorque |
4,613 kg (10,170 lbs) |
762 kg (1,680 lbs) |
395 hp |
410 lb-ft |
| 3.0L Hurricane I6 SO Twin-Turbo |
5,089 kg (11,220 lbs) |
835 kg (1,840 lbs) |
420 hp |
469 lb-ft |
| 3.0L Hurricane I6 HO Twin-Turbo |
4,536 kg (10,000 lbs) |
685 kg (1,510 lbs) |
540 hp |
521 lb-ft |
Which 2026 Ram 1500 Engine Is Right for Your Towing Needs?
3.6L Pentastar V6 with eTorque: The most fuel-efficient option at up to 11.0 L/100km combined (4x4), and leads the lineup in payload capacity at 812 kilograms. A solid choice for drivers who tow occasionally and prioritize everyday efficiency.
5.7L HEMI V8 with eTorque: The classic Ram engine delivers 395 hp and 410 lb-ft of torque with a proven reliability track record. At 4,613 kilograms (10,170 pounds) of max towing, it handles the majority of recreational towing needs like boats, campers, and utility trailers, with authority.
3.0L Hurricane SO Twin-Turbo: This is the engine for maximum towing capacity. At 5,089 kilograms (11,220 pounds), it leads the entire Ram 1500 lineup in max towing while also delivering 420 horsepower and 469 pound-feet of torque with better fuel economy than the V8. It's the best choice for drivers who regularly tow near or at the top of the half-ton segment.
3.0L Hurricane HO Twin-Turbo: With 540 horsepower and 521 pound-feet of torque, this is best-in-class available six-cylinder horsepower, which is more than any Chevy Silverado 1500, GMC Sierra 1500, or Toyota Tundra. While its towing figure is slightly lower than the SO due to GCWR differences, it's the engine for buyers who want the most powerful Ram 1500 available.
2026 Ram 1500 Cab & Bed Configurations
Towing and payload ratings vary by cab and bed configuration. Here are the key dimensions across available setups:
| Configuration |
Overall Length |
Bed Length |
Bed Width |
| Quad Cab — 6'4" Bed |
5,801 mm (228.4") |
1,938 mm (76.3") |
1,687 mm (66.4") |
| Crew Cab — 5'7" Bed |
5,903 mm (232.4") |
1,712 mm (67.4") |
1,687 mm (66.4") |
| Crew Cab — 6'4" Bed |
6,129 mm (241.3") |
1,938 mm (76.3") |
1,687 mm (66.4") |
2026 Ram 1500 Available Towing Technology
The 2026 Ram 1500 offers more available towing technology than any previous Ram 1500, including:
- Trailer Hitch Line-up Assist: This helps align the hitch and trailer coupler using the rear camera.
- Trailer Reverse Guidance with Dynamic Gridlines: This is on-screen guidance for backing a trailer accurately.
- Digital Rearview Mirror with Tow Mode: This provides clear rear visibility regardless of trailer obstruction
- Integrated Trailer Health Monitor: This monitors the trailer brake controller and connection status
- Power Telescoping Trailer Tow Mirrors: This extends automatically for improved visibility when towing
- Available Hands-Free Active Drive Assist: With eyes on the road, hands-free capability on specific roadways
Shop for the 2026 RAM 1500 at Provincial Chrysler in Windsor, ON
Whether you need the fuel efficiency of the V6, the proven capability of the HEMI, or the class-leading towing of the Hurricane SO, our team at Provincial Chrysler in Windsor is here to help you find the right Ram 1500 configuration. Come see us in person at 1001 Provincial Rd, Windsor, Ontario, N9W 5V9 or browse our current inventory online. Have a trade-in? We can help with a valuation too.
